Underwater Thruster / DW20
DW20 Underwater Thruster
A high-performance propulsion unit for medium-class ROVs, AUVs and unmanned surface vehicles, combining strong thrust, deep-water capability and a rugged, low-maintenance sealed design.
20 kgf
Max Thrust
910 W
Rated Power
350 m
Max Depth
48 V
Rated Voltage
Product Overview
Deep, dependable propulsion
The CubeMars DW20 is a 48 V underwater thruster that produces a maximum static (bollard) thrust of over 20 kgf and is rated for operation to about 350 metres. A streamlined nozzle reduces hydrodynamic drag to improve propulsion efficiency and lower electrical load.
The precision-cast aluminium alloy housing resists corrosion and impact, while a two-stage independent sealing chamber and low-friction dynamic shaft seal block sand, dust and water ingress for reliable, low-maintenance operation in demanding subsea environments.
Features & Benefits
Deep, dependable propulsion
A rugged thruster for medium-class underwater platforms.
Over 20 kgf Thrust
Strong propulsion for medium ROVs and AUVs.
350 m Rated
Built for inspection, survey and maintenance dives.
Cast Aluminium
Corrosion-resistant, impact-durable housing.
Dual-Seal Shaft
Two-stage sealing blocks sand, dust and water.
Streamlined Nozzle
Lower drag, higher thrust efficiency.
External Driver
Pairs with the TW-80A-12S underwater ESC.
Technical Specifications
DW20 Specifications
Verified CubeMars manufacturer specifications for the DW20.
Applications
Where the DW20 works
Built for medium-class marine platforms.
Inspection ROVs
Thrust for subsea inspection and survey.
AUVs
Reliable propulsion for autonomous vehicles.
Surface Vehicles
Drive for unmanned surface craft.
Research
Deep-water experimental platforms.
Why Choose This Product
Why the DW20
Powerful
Over 20 kgf of thrust.
Deep-Rated
Operates to 350 m.
Rugged
Cast aluminium, dual-sealed.
Support
Robomatek engineering assistance included.
Ready to integrate the DW20?
Talk to our robotics specialists for availability, lead time, and integration support.
